Specifications

• Manufacturer : Omron

• Product no : CP1W-MAD42

• Product type : Analog I/O Units

• Voltage I/O

• Number of inputs : 4 inputs (4 words allocated)

• Input signal range : 0 to 5 V, 1 to 5 V, 0 to 10 V, or –10 to 10 V

• Max. rated input : ±15 V

• External input impedance : 1 MO min.

• Resolution : 1/12000 (full scale)

• Number of outputs : 2 outputs (2 words allocated)

• Output signal range : 1 to 5 V, 0 to 10 V, or -10 to 10 V

• Conversion time : 1 ms/point (6 ms/all points)

• Isolation method : Photocoupler isolation between analog I/O terminals and internal circuits. No isolation between analog I/O signals.

• Current consumption : 5 VDC: 120 mA max., 24 VDC: 120 mA max

• Shipping Weight : 3 Kg
