PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller
  • PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller
  • PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller
  • PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller
  • PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller

PLC Cable Omron CS1D PLC CPU Module CS1D-CPU67H Programmable Logic Controller

Place of Origin China/Japan
Brand Name OMRON
Model Number CS1D-CPU67H
Product Details
Condition:
100% Original And New
Warranty:
1 Year
Package:
Original Packing
Shipping Ways:
DHL,FedEx,EMS
MOQ:
1 Piece
Color:
Black Or White
Model Number:
CS1D-CPU67H
Brand:
OMRON
Product Name:
Programmable Logic Controller
Packaging:
Original Carton
Port:
Selectable
High Light:

PLC Cable Omron CS1D

,

Omron CS1D CPU Module

,

CS1D-CPU67H

Payment & Shipping Terms
Minimum Order Quantity
1/pc
Price
$50-500
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

Omron plc cable Omron PLC CPU Module CS1D-CPU67H omron plc price list

CS1D adds a number of dual-redundancy options to the well-proven CS1 architecture to ensure around-the-clock operation without minimal downtime. Duplex CPUs, with or without loop control functions, are continuously cross-checked for errors, without the need for special programs to be written by the user. An even simpler way to increase system availability is to use dual power supply units. Hot swapping of CPUs, power supplies and I/O units allow system maintenance with little or no process interruption.

  • Choose the level of redundancy needed; CPU, power supply, communication
  • No special programming or software tools required
  • Hot-swapping of I/O units
  • All standard CS1 I/O units can be mounted
  • Ideal for control of power generators, water supply utilities, 24/7 production.

undefined



Specifications & ordering info
Ordering information
Max. Digital I/O points Program capacity Data memory capacity Logic execution speed Max. I/O units Additional functions Order code
5120 250K steps 448K words 20 ns 80 - CS1H-CPU67H
71 Supports duplex power supply and I/O hot-swapping CS1D-CPU67S
68 CPU for full dual-redundancy CS1D-CPU67H
CPU for full dual-redundancy, with loop control board CS1D-CPU67P
120K steps 256K words 80 - CS1H-CPU66H
60K steps 128K words 80 - CS1H-CPU65H
71 Supports duplex power supply and I/O hot-swapping CS1D-CPU65S
68 CPU for full dual-redundancy CS1D-CPU65H
CPU for full dual-redundancy, with loop control board CS1D-CPU65P
30K steps 64K words 80 - CS1H-CPU64H
20K steps - CS1H-CPU63H
60K steps 40 ns - CS1G-CPU45H
1280 30K steps 40 - CS1G-CPU44H
35 Supports duplex power supply and I/O hot-swapping CS1D-CPU44S
960 20K steps 30 - CS1G-CPU43H
10K steps - CS1G-CPU42H
26 Supports duplex power supply and I/O hot-swapping

CS1D-CPU42S





Accessories
Description   Remarks Order code
High-speed data collection and storage unit, with CF card slot and Ethernet port CPU bus unit CS1W-SPU01-V2
High-speed data collection and storage unit, with CF card slot and 2 Ethernet ports CPU bus unit CS1W-SPU02-V2
Duplex unit, required for CS1D-CPU6_H systems - CS1D-DPL01
Serial communication option board, 2 x RS-232C - CS1W-SCB21-V1
Serial communication option board, 1 x RS-232C + 1 x RS422/RS-485 - CS1W-SCB41-V1
Loop control option board 50 control blocks max. CS1W-LCB01
Loop control option board 300 control blocks max. CS1W-LCB05
Replacement battery set, for all CS1 CPUs - CS1W-BAT01
Compact Flash memory card, 128 MB, for all models (not required for operation) Industrial grade HMC-EF183
Compact Flash memory card, 256 MB, for all models (not required for operation) Industrial grade HMC-EF283
Compact Flash memory card, 512 MB, for all models (not required for operation) Industrial grade HMC-EF583
Compact Flash PC-Card adapter - HMC-AP001
CX-One, integrated software for programming and configuration of all Omron control system components - CX-ONE-AL__C-E
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port length: 2.0 m CS1W-CN226
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port length: 6.0 m CS1W-CN626
USB to serial conversion cable - CS1W-CIF31
