Inverter with the highest level of driving performance among the small size models.

[Features]
· Enhanced controllability with the M dial and increased expandability

· Compact body to save space.

· Equipped with advanced magnetic flux vector control, capable of starting high-precision general-purpose industrial machinery.

[Applications]
· Can be used for frequency control of motors.

Inverter

• Product Type : Inverter FR-E700 Series

• Applicable motor capacity (kW) : 15

• Output

  • Rated capacity (kVA) : 23.9

  • Rated current (A) : 60

  • Overload current rating : 150% 60s, 200% 3s (inverse-time characteristics)

  • Rated voltage : Three-phase 200 to 240V

  • Regenerative braking torque : 20%



• Power supply

  • Rated input AC (DC) voltage/frequency : Three-phase 200 to 240V 50Hz/60Hz

  • Permissible AC (DC) voltage fluctuation : 170 to 264V 50Hz/60Hz

  • Power supply capacity (kVA) : 28

  • Rated voltage : Three-phase 200 to 240V



• Cooling system : Forced air cooling

• Voltage Class : E720 = Three-phase 200V class

• Weight : 6.5 Kg

• Shipping Weight : 8 Kg
