MR-J2S-100A 3 Phase 200 to 230VAC Servo Drive

MR-J2S-100A 3-Phase 200 to 230VAC Servo Drive

• Mitsubishi Servo Drive MR-J2S 100W MR-J2S-10A
• Theinclusion of a high-resolution encoder ensures high performance and stability at low
• Motor sizes are the same as previous products and wiring is compatible
• The application of a high-performance CPU has enhanced response significantly. Speed loop frequency response is im- proved to 550Hz or
• The MR-J2-Super series are the best choice for use in high-speed positioning applications.
• The absolute positioning method, which does not require home position return, can be used by adding a battery to the servo amplifier. The servo motor does not need to be replaced

• Specification

• Control system	Sine-wave PWM control, current control system
  Dynamic brake	Built-in
  Protective functions	Overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal relay), servo motor overheat protection, encoder error protection, regenerative error protection, undervoltage, instantaneous power failure protection, overspeed protection, excessive error protection
  Max. input pulse frequency	500kpps (for differential receiver), 200kpps (for open collector)
  Command pulse multiplying factor	Electronic gear A:1 to 65535 131072 B:1 to 65535, 1/50 A/B 500
  In-position range setting	0 to 10000 pulse (command pulse unit)
  Error excessive	(Note) 2.5 revolutions
  Torque limit	Set by parameter setting or external analog input (0 to 10VDC/maximum torque)
  Speed control range	Analog speed command 1: 2000, internal speed command 1: 5000
  Analog speed command input	0 to 10VDC / Rated speed
  Speed fluctuation ratio	0.01% or less (load fluctuation 0 to 100%) 0% (power fluctuation 10%) 0.2% or less (ambient temperature 25 10 (59 to 95 )), when using analog speed command

•

Zhinian have large range of stock quantity ,we would shop out the products within 1 or 2 days after payment .If you need special help,we would try our best to help you.We are shipping the goods to every country of the world! Our shipping method such as DHL , Fedex, UPS and so on.
