CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP
  • CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP
  • CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP

CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP

Place of Origin China/Japan
Brand Name Omron
Model Number CJ2M-CPU32
Product Details
Service:
One-stop Service
Package:
Original Package
Quality:
New And Original
Lead Time:
In Stock
Warrenty:
1 Year
Delivery Detail:
3-5 Working Days After Payment
Max. Digital:
2,560
Logic Execution Speed:
16 Ns
Width:
80 Mm
Port:
Guangdong Shenzhen Dongguan
Warranty:
1 Year
Condition:
100% Original
Product Name:
Omron
Shipping Term:
DHL,TNT,UPS
Type:
PLC
High Light:

CJ2M-CPU32 CPU PLC

,

CPU PLC Omron Sysmac CJ2M

Payment & Shipping Terms
Minimum Order Quantity
1/pc
Price
$450-$1500
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP



Product Features

CJ2M for basic machine automation

The CJ2M Series is ideal for packaging and general machine automation needs. Connectivity is assured thanks to the built-in USB port and the choice of Ethernet and RS-232C/422/485 interfaces on the CPU.

  • Always accessible through standard USB port
  • Standard Ethernet port with EtherNet/IP Data Link function
  • Wide range of program capacities from 5K steps to 60K steps
  • Serial option board
  • Dedicated function block memory ensures efficient execution of function block software module
Related Products

 CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP 0

Specification

Max. digital
I/O points

Program capacity

Data memory capacity

Logic execution speed

Max. I/O units

Width

5 V current
consumption

Built-in functions

Order code

2,560

400 K

832 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU68-EIP

2,560

250 K

512 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU67-EIP

2,560

150 K

352 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU66-EIP

2,560

100 K

160 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU65-EIP

2,560

50 K

160 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU64-EIP

2,560

60 K

160 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU35

2,560

30 K

160 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU34

2,560

20 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU33

2,560

10 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU32

2,560

5 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU31



Images



 CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP 1CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP 2CJ2M-CPU32 CPU PLC Omron Sysmac CJ2M 16 NS USB EtherNet/IP 3

Accessories



Description

Remarks

Order code

High-speed data collection and storage unit, with CF card slot and Ethernet port

CPU bus unit

CJ1W-SPU01-V2

Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs

NPN (sinking) outputs

CJ2M-MD211

Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs

PNP (sourcing) outputs

CJ2M-MD212

CompactFlash memory card, 128 MB, for all models (not required for operation)

Industrial grade

HMC-EF183

CompactFlash memory card, 256 MB, for all models (not required for operation)

Industrial grade

HMC-EF283

CompactFlash memory card, 512 MB, for all models (not required for operation)

Industrial grade

HMC-EF583

CompactFlash PC-Card adapter

-

HMC-AP001

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

Push-in

XW2R-P40G-T

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

Clamp

XW2R-E40G-T

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

M3 Screws

XW2R-J40G-T

Connection cable between I/O terminal block and CJ1M-CPU2_/CJ2M-MD21_ ( ____ = length in cm)

MIL (40 pt)

XW2Z-____FF-L

Servo unit terminal block for 1 axis

-

XW2B-20J6-8A

Servo unit terminal block for 2 axes

-

XW2B-40J6-9A

SMARTSTEP cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m

-

XW2Z-100J-A26

W-series servo cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m

-

XW2Z-100J-A27

CX-One, integrated software for programming and configuration of all Omron control system components

-

CX-ONE-AL__C-E

Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 2.0 m)

-

CS1W-CN226

Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 6.0 m)

-

CS1W-CN626

USB to serial conversion cable

-

CS1W-CIF31

RS-232C Option Board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF01

RS-422A/485 Option board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF11

RS422A/485 (isolated) Option board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF12

Battery Set

2
2. Included with the CPU unit

-

CJ1W-BAT01

USB Programming cable

-

CP1W-CN221
