| Place of Origin | China/Japan |
| Brand Name | Omron |
| Model Number | CJ2M-CPU35 |
The CJ2M Series is ideal for packaging and general machine automation needs. Connectivity is assured thanks to the built-in USB port and the choice of Ethernet and RS-232C/422/485 interfaces on the CPU.
| Program capacity | 80 K steps |
| Data memory capacity | 160 K words |
| Logic execution time | 0.04 µs |
| Max. number of expansion units | 40 |
| Max. number of local I/O points | 2560 |
| Number of built-in digital I/Os | 0 |
| Communication port(s) | EtherNet/IP, Ethernet TCP/IP, USB |
| Height | 90 mm |
| Width | 62 mm |
| Depth | 84.5 mm |
| Weight | 190 g |
|
Description |
Remarks |
Order code |
|---|---|---|
|
High-speed data collection and storage unit, with CF card slot and Ethernet port |
CPU bus unit |
CJ1W-SPU01-V2 |
|
Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs |
NPN (sinking) outputs |
CJ2M-MD211 |
|
Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs |
PNP (sourcing) outputs |
CJ2M-MD212 |
|
CompactFlash memory card, 128 MB, for all models (not required for operation) |
Industrial grade |
HMC-EF183 |
|
CompactFlash memory card, 256 MB, for all models (not required for operation) |
Industrial grade |
HMC-EF283 |
|
CompactFlash memory card, 512 MB, for all models (not required for operation) |
Industrial grade |
HMC-EF583 |
|
CompactFlash PC-Card adapter |
- |
HMC-AP001 |
|
I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_ |
Push-in |
XW2R-P40G-T |
|
I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_ |
Clamp |
XW2R-E40G-T |
|
I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_ |
M3 Screws |
XW2R-J40G-T |
|
Connection cable between I/O terminal block and CJ1M-CPU2_/CJ2M-MD21_ ( ____ = length in cm) |
MIL (40 pt) |
XW2Z-____FF-L |
|
Servo unit terminal block for 1 axis |
- |
XW2B-20J6-8A |
|
Servo unit terminal block for 2 axes |
- |
XW2B-40J6-9A |
|
SMARTSTEP cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m |
- |
XW2Z-100J-A26 |
|
W-series servo cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m |
- |
XW2Z-100J-A27 |
|
CX-One, integrated software for programming and configuration of all Omron control system components |
- |
CX-ONE-AL__C-E |
|
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 2.0 m) |
- |
CS1W-CN226 |
|
Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 6.0 m) |
- |
CS1W-CN626 |
|
USB to serial conversion cable |
- |
CS1W-CIF31 |
|
RS-232C Option Board 1
1. Only used with CJ2M-CPU3_
|
- |
CP1W-CIF01 |
|
RS-422A/485 Option board 1
1. Only used with CJ2M-CPU3_
|
- |
CP1W-CIF11 |
|
RS422A/485 (isolated) Option board 1
1. Only used with CJ2M-CPU3_
|
- |
CP1W-CIF12 |
|
Battery Set 2
2. Included with the CPU unit
|
- |
CJ1W-BAT01 |
|
USB Programming cable |
- |
CP1W-CN221 |
