CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU
  • CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU
  • CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU

CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU

Place of Origin China/Japan
Brand Name OMRON
Model Number CJ2M-CPU31
Product Details
100% Original And New
One Year
Original Packing
Shipping Ways:
1 Piece
Model Number:
Product Name:
Programmable Logic Controller
Original Carton
Shipping Term:
High Light:

PLC Controllers CJ2M CPU


Omron Automation PLC Controllers CJ2M

Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

CJ2M-CPU31 Omron Automation and Safety PLC Controllers CJ2M CPU

SYSMAC CJ-series CJ2M CPU Units, Pulse I/O Modules

  • Increased performance, and increased memory capacity
  • Up to 40 I/O unit on any CPU
  • Pulse I/O Modules add position control functions to any CPU
  • USB for plug-and-play access to the PLC
  • All models available with or without Ethernet port
  • Choice of serial port plug-in modules

  • Five variations in program capacity from 5K steps to 60K steps; scale the CPU to your application needs.
  • Faster processors; LD instruction execution time is reduced to 40 ns, floating point trigonometrics in less than 1 µs.
  • Optional Pulse I/O Modules can be mounted to enable positioning functions for up to four axes. The module provides high-speed counters, interrupt inputs and pulse train/PWM outputs. (CJ2M CPU Units with Unit Version 2.0 or Later)
  • Faster Function Block calls and execution, faster interrupt handling, less overhead time.
  • Added execution memory for Function Blocks allows structured, object-oriented programming even in entry-level CPUs.
  • General-purpose Ethernet port supports EtherNet/IP tag-based data links, connection to Support Software, communications between PLCs, FTP data transfers, and more (CJ2M-CPU3☐).
  • Standard USB port on all models allows Support Software to connect directly through standard USB cable.
  • A Serial Option Module can be mounted to add RS-232C or RS-422A/485 communications ports (CJ2M-CPU3☐).
  • Compatible with all existing CJ1 power supply-, I/O-, control- and communication units.
Attribute Value
For Use With CJ2M Series
Manufacturer Series CJ2M
Output Type Pulse
Voltage Category 5 V dc
Network Type Ethernet
Display Included Yes
Communication Port Type USB 2.0
Program Capacity 5000 Steps
Programming Language Used Instruction List, Ladder Logic, SFC, Structured Text
Programming Interface Computer
Width 95.4mm
Depth 84.5mm
Battery Backup Yes
Number of Communication Ports 1
Dimensions 62 x 95.4 x 84.5 mm
Length 62mm
Maximum Operating Temperature +55°C
Memory 5K (Program Memory) Steps, 64K (Data Memory) Words
Minimum Operating Temperature 0°C



CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU 0CJ2M-CPU31 Omron Automation Safety PLC Controllers CJ2M CPU 1
