| Place of Origin | China |
| Brand Name | Omron |
| Model Number | CJ1W-OD262 |
| Digital Input Type | None |
|---|---|
| Digital Output Type | PNP |
| Compliant With Standard(S) | cULus (Class I Division 2 Products for Hazardous Locations) |
| Connection Type | MIL connector |
| Current Consumption | (5Vdc) 0.17 A |
| Detachable I/O Connector | 1 |
| Digital Outputs | 64 x digital outputs (12Vdc-24Vdc, Source, 0.3A) |
| Expansion Unit Type | Basic I/O Unit |
| For Use With | CJ2 Family PLC |
| Functions | DC digital output unit |
| I/O Connection Type | MIL (plug not included) |
| I/O System | CJ I/O Bus |
| Legislation And Compliance | RoHS Certificate of Compliance |
| Main Function | I/O unit |
| Manufacturer Product Status | Commercialized |
| Mounting Mode | DIN rail |
| Number Of I/O Connectors | 2 |
| Number Of Iog (V-) Terminals | 8 |
| Number Of Iov (V+) Terminals | 8 |
| Positions Per I/O Connector | 40 |
| Product Depth | 83.6 mm |
| Product Height | 95.4 mm |
| Product Series / Family Name | SYSMAC CJ1 series |
| Product Width | 31 mm |
| Range | CJ |
| Sub-Range Name | CJ1W-OD |
| Type Of Module | Digital I/O |
