Mitsubishi Servo Motor
>
|
| Place of Origin | Japan/ China |
| Brand Name | Mitsubishi |
| Model Number | HC-RFS203 |
HC-RFS203 Mitsubishi Melservo General-Purpose AC Servo Motor
This unit ships as shown, with the gearhead attached.
Configuration:
• Rated Output: 2kW
• Rated Speed: 3000 r/min
• Electromagnetic Brake: Without
• Reduction Gear: Without
• Shaft Type: Standard (Straight Shaf
| Type | HC-RFS |
| Rated Torque (Nm) | 6,37 |
| Maximum Torque (Nm) | 15,9 |
| Rated Speed (rpm) | 3000 |
| Maximum Speed (rpm) | 4500 |
| Inertia (kg*cm2) | 2,3 |
| Brake | NO |
| Shaft Type | STRAIGHT SHAFT |
| Protection Class | IP65 |
| Power Supply (V) | 200 |
| Current Type | AC |
| Encoder Resolution (p/rev) | 131072 |
| Width (mm) | 100 |
| Height (mm) | 100 |
| Depth (mm) | 197 |
| Weight (kg) | 6,2 |
| European Order Code | 134855 |
| Global Order Code | 0HG303 |
| Product hierarchy | IAK30206 |
| Class Description | FA-Servo-Motion: Servo Motor |
| External Material Group | Discontinued Material |
| Logistic Class | C |
| Gross Weight | 7.5 KG |
| Volume | 18.4 CDM |
| Length | 50 CM |
| Width | 16 CM |
| Height | 23 CM |
| Commodity Code | 85015220 |
| Country of Origin | JP |
| Predecessor | 68955 |
| Discontinued (EOL) | 07.11.2013 |
| Last Time Buy (LTB) | 31.08.2015 |
| End of Service (EOS) | 31.08.2022 |
| Successor | 262898 HG-RR203 |
| Successor Information | SYSTEM CHANGE REQUIRED |
