FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module
  • FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module
  • FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module
  • FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module

FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module

Place of Origin China/Japan
Brand Name MITSUBISHI
Model Number FX2N-4AD-PT
Product Details
Max Input /output Points:
16 Points
Supply Voltage:
100-240VAC
Input Points:
8 Points.
Output Points:
8 Points
Output Type:
Relay
Power Consumption:
30W
Weight:
0.6 Kg
Dimension (WxHxD):
130x90x86mm
Port:
Selectable
Model Number:
FX2N-4AD-PT
High Light:

FX2N-4AD-PT

,

Mitsubishi Electric Input Block I/O Module

Payment & Shipping Terms
Minimum Order Quantity
1/pc
Price
$50-$500
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

FX2N-4AD-PT Mitsubishi Electric Input Block I/O Module





Product Details



Additional Modules for Mitsubishi FX1S, FX1N & FX2N PLC's



Products in this range are for use with FX1S, FX1N and FX2N PLC, unless specified otherwise. All are DIN rail mount and are 90mm high and 87mm deep. The width varies and is tabled below.



All of the following products, except the Extension Cable, attach directly to the right hand end of the previous unit, block or module using the short integral lead.


Attribute Value
For Use With FX2N Series, FX3U Series
Input Type Analogue
Series FX2N Series, FX3U Series
Maximum Operating Temperature +55°C
Dimensions 90 x 55 x 87 mm





Plc.analog Input Fx2n-4ad-pt.for Equipment.industrial Tool - AliExpress

  • Manufacturer : Mitsubishi Electric

  • Product No. : FX2N-4AD-PT

  • Product type : Input Block I/O Module

  • Description : Programmable Controllers, Input Block I/O Module

  • Channel : 4 CH Input

  • Input types : 3-wire platinum resistance thermometer sensor(s) Pt100

  • Compensated range : -100 to +600°C / -148 to +1112°F

  • Resolution : 0.2 to 0.3°C / 0.36 to 0.54°F

  • Digital Output : -1000 to +6000 (°C) / -1480 to +11120 (°F)

  • Accuracy : ±1% of full scale

  • Conversion time : 15ms / 1 channel

  • No. of Occupied Points : 8 I/O points

  • Applicable PLC : FX1N / FX2N / FX2NC / FX3U

  • Certifications : CE, UL/cUL

  • Dimensions (HxWxD), approx : 9cm x 5.5cm x 8.7cm

  • Shipping Weight : 3 Kg

  •
