| Place of Origin | China/Japan |
| Brand Name | MITSUBISHI |
| Model Number | FX5U-80MR/ES |
FX5U-80MR/ES FX5U series iQ platform compatible programmable logic controller
The Mitsubishi FX5U series iQ platform compatible programmable logic controller (PLC) has 16 digital input (type 24VDC sink/source) and 16 relay/transistor outputs. MELSEC communication protocol (3C/4C Frames) and MELSOFT connection. It has 64k steps program capacity and 16 built-in inputs. The FX5U continues the FX tradition of total flexibility by offering a huge range of new and existing add-on options. It further enhances the built-in functions of Ethernet, analogue I/O, data logging, position control, security, communication and networking functions incorporated as a standard. It will provide users with the ability to specify more powerful systems, but with fewer overall components, saving time and cost.
Voltage rating ranges between 100VAC and 240VAC
Expanded input/output area for networks and complex applications
Can be upgraded by combining with expansion modules
Built-in SD card slot
Voltage rating ranges between 100VAC and 240VAC
Run/Stop/Reset switch
Built-in Ethernet port, RS485
Displays the input and output states via LEDs
Integrated real-time clock
Programming software is GX Works3
Operating temperature ranges between 0°C and 55°C
Industrial automation
Robotics
Automobile industry
CUL
EC directive
EMC directive
UL listed
IP10 rated
| Attribute | Value |
| For Use With | MELSEC IQ-F Series IQ Platform-Compatible PLC |
| Manufacturer Series | FX5U |
| Number of Inputs | 16 |
| Output Type | Relay, Transistor |
| Input Type | Sink, Source |
| Voltage Category | 100 → 240 V ac |
| Number of Outputs | 16 |
| Network Type | Inverter Communication, MELSEC Communication protocol (3C/4C Frames), MELSOFT Connection, Modbus RTUI, N:N Network, Predefined Protocol Support, SLMP (3E Frame), Socket Communication |
| Communication Port Type | Ethernet, RS485 |
| Program Capacity | 64 k Steps |
| Mounting Type | Panel Mount |
| Programming Language Used | FBD, Ladder Diagram, ST |
| Programming Interface | RJ45 Connector (Ethernet Communication) |
| Number of Communication Ports | 2 |
| Width | 90mm |
| Length | 150mm |
| Depth | 83mm |
| Standards Met | CE, cULus Listed |
| Dimensions | 150 x 90 x 83 mm |
| Minimum Operating Temperature | 0°C |
| Memory | 120 (Device Memory) kB, 5 (Data Memory) MB, 64 (Program Capacity) k steps |
| Maximum Operating Temperature | +55°C |
