DC 24V Proface Display PFXGP4401WADW HMI Touch Screen 7 inch
GP4000 series has high connectivity with a wide range of industrial controllers and provides a variety of lineup in sizes, front colours, coating, and open frame. Pro-face Standard HMI, GP4000 Series flexibly satisfies customers' needs.
Functional Specifications
| Display Type |
TFT Color LCD
|
|---|---|
| Display Size |
7.0"
|
| Resolution |
800 x 480 pixels (WVGA)
|
| Effective Display Area |
W152.4 x H91.44 mm [W6.0 x H3.6 in.]
|
| Display Colors |
65,536 Colors (No blink)/16,384 Colors (Blink)
|
| Backlight |
White LED (User nonreplaceable parts. When replacement is required, contact your local distributor.)
|
| Brightness Control |
8 Levels (Adjusted with the touch panel or the software)
|
| Backlight Service Life |
50,000 hrs. or more (continuous operation at 25°C [77 °F] before backlight brightness decreases to 50%)
|
| Language Fonts |
Japanese: 6,962 (JIS Standards 1 & 2) (including 607 non-kanji characters) ANK: 158 (Korean fonts, Simplified Chinese and Traditional Chinese fonts are downloadable.)
|
| Character Sizes |
Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts, Stroke font: 6 to 127 pixel fonts, Image font: 8 to 72 pixel fonts
|
| Font Sizes |
Standard font: Width can be expanded up to 8 times. Height can be expanded up to 8 times.
|
| 8 x 16 dots |
100 char. x 30 rows
|
| 16 x 16 dots |
50 char. x 30 rows
|
| 32 x 32 dots |
25 char. x 15 rows
|
| 8 x 8 dots |
100 char. x 60 rows
|
| Program Area |
FLASH EPROM 132 KB (Equivalent to 15,000 steps)*1
|
| Variable Area |
None
|
| Application Memory |
FLASH EPROM 16 MB (including a logic program area)
|
| Data Backup |
SRAM 128 KB (Replaceable Lithium battery for backup memory)
|
| Clock Accuracy |
±65 sec/month (deviation at room temperature and power is OFF)*2
|
| Touch Panel Type |
Resistive Film (analog)
|
| Touch Panel Resolution |
1,024 x 1,024
|
| Touch Panel Service Life |
1,000,000 times or more
|
| Serial (COM1) |
RS-232C Asynchronous Transmission Data Length: 7 or 8 bits, Parity: none, Odd or Even, Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug)
|
| Serial (COM2) |
RS-422/485 Asynchronous Transmission Data Length: 7 or 8 bits, Parity: none, Odd or Even Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI) Connector: D-Sub9 (plug)
|
| Ethernet (LAN) |
IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX Connector: Modular jack (RJ-45) x 1
|
| USB (TYPE-A) |
Conforms to USB2.0 (TYPE-A) x 1, Power Supply Voltage: DC 5 V ±5 %, Output Current: 500 mA or less, Communication Distance: 5 m [16.4ft.] or less
|
| USB (mini-B) |
Conforms to USB2.0 (mini-B) x 1, Communication Distance: 5 m [16.4ft.] or less
|
| SD Card |
SD Card Slot x 1
|
1Up to 60,000 steps can be converted in software. However, this reduces application memory capacity (for screen data) by 1 MB.
2Depending on the operating temperature and age of unit, the clock can deviate from -380 to +90 sec/month. For systems where this level of deviation is a problem, the user should monitor and make adjustments when required.
General Specifications
| International Safety Standards |
|
|---|---|
| Rated Input Voltage |
DC 24V
|
| Input Voltage Limits |
DC 19.2 to 28.8V
|
| Allowable Voltage Drop |
5 ms or less
|
| Power Consumption |
12 W or less
|
| In-Rush Current |
30 A or less
|
| Voltage Endurance |
AC 1,000 V, 20 mA for 1 min (between charging and FG terminals)
|
| Insulation Resistance |
DC 500 V, 10 MΩ or more (between charging and FG terminals)
|
| Surrounding Air Temperature |
0 to 50 °C (32 to 122 °F)
|
| Storage Temperature |
-20 to 60 °C (-4 to 140 °F)
|
| Ambient Humidity |
10 to 90 % RH (Wet bulb temperature: 39 °C [102.2 °F] or less - no condensation.)
|
| Storage Humidity |
10 to 90 % RH (Wet bulb temperature: 39 °C [102.2 °F] or less - no condensation.)
|
| Dust |
0.1 mg/m³ (10<sup>-7</sup> oz/ft³) or less (non-conductive levels)
|
| Pollution Degree |
For use in Pollution Degree 2 environment
|
| Atmosphere |
Free of corrosive gases
|
| Air Pressure (altitude range) |
800 to 1,114 hPa (2,000 m [6,561ft.] above sea level or less)
|
| Vibration Resistance |
IEC/EN61131-2 compliant, 5 to 9 Hz Single amplitude 3.5 mm [0.14 in.], 9 to 150 Hz Fixed acceleration: 9.8 m/s², X, Y, Z directions for 10 cycles (approx. 100 min)
|
| Concussion Resistance |
IEC/EN61131-2 compliant 147 m/s², X, Y, Z directions for 3 times
|
| Noise Immunity |
Noise Voltage: 1,000 Vp-p, Pulse Duration: 1 µs, Rise Time: 1 ns (via noise simulator)
|
| Electrostatic Discharge Immunity |
Contact Discharge Method: 6 kV (IEC/EN61000-4-2 Level 3)
|
| Grounding |
Functional grounding: Grounding resistance of 100Ω, 2mm² (AWG 14) or thicker wire, or your country's applicable standard. (Same for FG and SG terminals)
|
| Structure |
IP65f NEMA #250 TYPE 4X/13 (on the front panel when properly installed in an enclosure)*3
|
| Cooling Method |
Natural air circulation
|
| Weight Approx. |
1.2 kg [2.6 lb] or less (display unit only)
|
| External Dimensions |
W218 x H173 x D60 mm [W8.58 x H6.81 x D2.36 in.]
|
| Panel Cut Dimensions |
W204.5 x H159.5 mm [W8.05 x H6.28 in.], Panel thickness area: 1.6 to 5 mm [0.06 to 0.2 in.]*4
|
