CP1E-N30DT1-A Omron PLC CP1E Power Module Control Unit 120 - 240V aC

Hot sale PLC New original module CP1Eseries CP1E-N30DT1-A power module

Features:

• Lineup including CPU Units with built-in three ports: USB, RS-232C, RS-485
• The depth of CPU Units with RS-232C connectors is reduced by 20 mm. (N30/40/60S(1))
• Easy connection with computers using commercially available USB cables
• With E30/40/60(S), N30/40/60(S@) or NA20 CPU Units, Add I/O, Analog I/O or Temperature Inputs by Connecting Expansion Units or Expansion I/O Units
• Input interrupts
• Complete High-speed Counter Functionality
• Versatile pulse control for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units
• PWM Outputs for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units
• Mounting Serial Option Boards, Ethernet Option Board and Analog Option Board to N30/40/60 or NA20 CPU Units
• Built-in analog I/O, two inputs and one output, for NA-type CPU Units

Item Specifications

• SeriesCP1
• Type of Unit
  Control Unit
• Built in IO30
• Total IO Capacity
  150
• Supply Voltage120 - 240 Vac
• # of Inputs and Type
  18 Inputs NPN or PNP
• # of Outputs and Type12 Outputs PNP
• Expandable
  3 Expansion IO
• # of Option Modules1
• Display
  No
• CommunicationsUSB, RS232C, 1 Option Port
• Real Time Clock
  Yes
• Battery BackupOption CP1W-BAT01
• Analog
  2 Inputs, 1 Output
• Mounting TypeDin Rail
• Software
  CX One
