70VA Omron Power Supply Distributor PLC MODULE CP1E-E10DR-D
  • 70VA Omron Power Supply Distributor PLC MODULE CP1E-E10DR-D
  • 70VA Omron Power Supply Distributor PLC MODULE CP1E-E10DR-D

70VA Omron Power Supply Distributor PLC MODULE CP1E-E10DR-D

Place of Origin China/Japan
Brand Name Omron
Model Number CP1E-E10DR-D
Product Details
Series:
CP1E Series
Power Supply:
100-240V AC,50/60Hz, 70VA
Output Type:
Relay
Inputs:
6
Outputs:
4
Warranty:
1 Year
PAYMENT:
TT.Western Union
Lead Time:
In Stock
Port:
Selectable
Application:
INDUSTRIAL AUTOMATION
MOQ:
1 PC
High Light:

70VA Omron Power Supply Distributor

,

PLC Omron Power Supply Distributor

,

CP1E-E10DR-D

Payment & Shipping Terms
Minimum Order Quantity
1/pc
Price
$50-500
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

Promotion selling Distributor PLC MODULE CP1E-E10DR-D Programmable Logic Controller



  • Powerful compact PLC for small and middle size machine controls
  • Built-in high speed counter and pulse output functionality
  • USB interface for programming and monitoring



CP1E external appearance

General Specifications
Type AC Power Supply Type DC Power Supply Type
Format Model CP1E-□□□S□D□-A
Model CP1E-□□□D□-A
Model CP1E-□□□S□D□-D
Model CP1E-□□□D□-D
Structure Built into panel type
External Shape: Height × Depth × Width E/N/NA□□ Type
10-point input/output type (Model CP1E-E10D□-□): 90 mm (*1) × 85 mm (*2) × 66 mm
14/20 point input/output type (Model CP1E-□14/20D□-□): 90 mm (*1) × 85 mm (*2) × 86 mm
30-point input/output type (Model CP1E-□30D□-□): 90 mm (*1) × 85 mm (*2) × 130 mm
40-point input/output type (Model CP1E-□40D□-□): 90 mm (*1) × 85 mm (*2) × 150 mm
60-point input/output type (Model CP1E-N60D□-□): 90 mm (*1) × 85 mm (*2) × 195 mm
Analog built-in 20-point input/output type (Model CP1E-NA20D□-□): 90 mm (*1) × 85 mm (*2) × 130 mm
E/N□□S(1) type
14/20-point input/output type (Model CP1E-E14/20SD□-□): 90 mm (*1) × 79 mm (*2) × 86 mm
30-point input/output type (Model CP1E-□30S(1)D□-□): 90 mm (*1) × 79 mm (*2) × 130 mm
40-point input/output type (Model CP1E-□40S(1)D□-□): 90 mm (*1) × 79 mm (*2) × 150 mm
60-point input/output type (Model CP1E-□60S(1)D□-□): 90 mm (*1) × 79 mm (*2) × 195 mm
Weight 10-point input/output type (Model CP1E-E10D□-□): 300 g or less
14-point input/output type (Model CP1E-□14(S)D□-□): 360 g max.
20-point input/output type (Model CP1E-□20(S)D□-□): 370 g max.
30-point input/output type (Model CP1E-□30(S□)D□-□): 600 g max.
40-point input/output type (Model CP1E-□40(S□)D□-□): 660 g max.
60-point input/output type (Model CP1E-□60(S□)D□-□): 850 g max.
Analog built-in 20-point input/output type (Model CP1E-NA20D□-□): 680 g max
Power
Supply
Specifications
Power Supply Voltage 100 to 240 V AC 50/60 Hz 24 V DC
Allowable Power Supply Voltage 85 to 264 V AC 20.4 to 26.4 V DC
Power Consumption 15 VA / 100 V AC max.
25 VA/240 V AC max.
(Model CP1E-□10/14/20(S)D□-A)
9 W max. (Model CP1E-E10D□-D)
13 W max. (Model CP1E-N14/20D□-D)
50 VA/100 V AC max.
70 VA/240 V AC max.
(Model CP1E-□30/40/60(S□)D□-A, Model CP1E-NA20D□-A)
20 W max.
(Model CP1E-N30/40/60(S□)D□-D, Model CP1E-NA20D□-D) (*4)
Inrush Current 120 V AC 20 A / 8 ms max. (with room temperature cold start)
240 V AC 40 A / 8 ms max. (with room temperature cold start)
24 V DC 30 A / 20 ms max. (with room temperature cold start)
External Supply Power Supply (*3) None (Model CP1E-□10/14/20(S)D□-A)
24 V DC 300 mA max. (Model CP1E-□30/40/60D□-A, Model CP1E-□30/40/60SDR-A, Model CP1E-NA20D□-A)
None
Insulation Resistance Between the external AC terminals and GR terminals
20 M٠min. (500 V DC insulation resistance���)
Except between DC primary current and DC secondary current.
Dielectric Strength Between the external AC terminals and GR terminals
2,300 V AC 50/60 Hz for 1 min, leakage current 5 mA max.
Except between DC primary current and DC secondary current.
Power OFF Detection Time 10 ms min. 2 ms min.
Operating
Environment
Ambient Operating Temperature 0 to 55°C
Ambient Operating Humidity 10 to 90% RH
Operating Ambient Atmosphere Must be no corrosive gas
Ambient Storage Temperature -20 to +75°C (excluding battery)
Operating Altitude 2,000 m max.
Pollution Pollution degree 2 or less: conforms to JIS B3502, IEC61131-2
Noise resistance IEC61000-4-4 compliant 2 kV (power supply line)
Overvoltage Category Category II: conforms to JIS B3502, IEC61131-2
EMC Immunity Level Zone B
Vibration Resistance JIS C60068-2-6 compliant
5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz
Acceleration of 9.8 m/s2 for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)
Shock Resistance JIS C60068-2-27 compliant
147 m/s2 3 times in X, Y, and Z directions
Terminal Block Fixed type (not removable)
Terminal Screw Size M3
Approved Standards EC directive
Grounding Method D type grounding (No. 3 type grounding)

Note. The expansion I/O unit and expansion unit general specifications use the same conditions as for the CPU unit.
* 1. Total of 110 mm with mounting brackets
*2. Excluding cables
*3. Use the external power supply to power input devices. Do not use it to drive output devices.
* 4. This is the rated value for the maximum system configuration. Use the following formula to calculate power consumption for DC power types.
Formula:
DC power consumption = (5 V current consumption) × 5 V/70% (CP1L internal power efficiency) + (24 V current consumption) × 1.1 (current fluctuation factor)
Use the calculation result of the above to select a DC power supply allowing a sufficient margin.

  • *See the catalog for performance specifications and dimensional outline drawings.
