FX3U-64MR/ES-A PLC Industrial Automation / Mitsubishi PLC Module Relay Output

Place of Origin China/Japan
Brand Name Mitsubishi
Model Number FX3U-64MR/ES-A, FX3U-64MR/ES-A
Product Details
Brand Name:
Mitsubishi
Delivery Time:
3-4 Orking Days
Shipping By:
DHL,UPS,Fedex And EMS
Lead Time:
In Stock
Package:
Original Package
Color:
White
Company Location:
Changsha City, China
Shipping Cost:
As You Country
Warranty:
1 Year
Port:
As Your Selection
High Light:

FX3U-64MR PLC Industrial Automation

,

Relay PLC Industrial Automation

,

FX3U-64MR Mitsubishi PLC Module

Payment & Shipping Terms
Minimum Order Quantity
1/pc
Price
$100.00 - $500.00/Pieces
Packaging Details
Carton packaging
Payment Terms
T/T, western union
Supply Ability
10pc/per week
Product Description

FX3U-64MR/ES-A PLC Industrial Automation / Mitsubishi PLC Module Relay Output

Description

Mitsubishi FX3U-64MR/ES-A PLC Base Unit FX3U64MRESA 09S211

  • Extended Product Type: FX-series
  • Product ID: FX3U-64MR/ES-A
  • Mitsubishi Type Designation: FX-series

Description of Mitsubishi FX3U-64MR/ES-A PLC Base I/O Unit

Mitsubishi FX3U-64MR/ES-A High-end Programmable Logic Controller (PLC) CPU main unit with integrated I/Os – (MELSEC-F (FX) Series FX3U) – 64I/O [32DI (32 x digital inputs (24Vdc; Sink/Source)) + 32DO (32 x digital outputs (Rly NO contacts; 2A / 240Vac or 30Vdc; 10ms response))] – 64Ksteps (RAM; Program) memory capacity – connection capacity 256 x I/O points – with screw-clamp term. connections (I.O’s) – with RS-422 communication capability – Supply voltage 100Vac-240Vac (120Vac / 208Vac / 220Vac / 230Vac) – DIN rail mounting (220mm width) – equivalent to FX3U64MRESA

Features of Mitsubishi FX3U-64MR/ES-A PLC Base Unit

  • Three memory cassettes that can be installed into the FX3U CPU, and when installed the memory cassette’s internal program is used in place of the internal RAM memory. The FX3U-FLROM-64L (stock no. 539-0853) features program transfer buttons to allow permanent overwriting of the RAM based-program. FX3U battery – this battery buffers the internal RAM memory of the FX3U in the event of a power supply failure. FX3U-USB-AW converts USB interface to RS422 to allowing direct programming of FX3U PLCs using a PC’s USB port with either GX Developer or GX IEC Developer programming software.
  • Flash ROM modules in 16kB and 64kB sizes with a program loader version of the 64k to allow program transfer to/from PLC’s.

Specifications of Mitsubishi FX3U-64MR/ES-A PLC Base Unit

  • Primary brand: Mitsubishi Electric
  • Main function: CPU unit
  • Product series / family name: MELSEC-F (FX) Series
  • Sub-range name: FX3U
  • Functions: High-end Programmable Logic Controller (PLC) CPU main unit with integrated I/Os, Program execution type — Cyclical / Refresh mode processing
  • Supply voltage (AC): 100Vac-240Vac (120Vac / 208Vac / 220Vac / 230Vac)
  • Memory capacity: 64Ksteps (RAM; Program)
    • 7680 points (Auxiliary relays)
    • 512 points (Timers)
    • 235 points (Counters)
    • 8000 points (Data registers)
    • 32768 points (Extension registers)
  • Connection capacity: 256 x I/O points, 384 x I/O points (with CC-Link or AnyWireASLINK)
  • Connection type: screw-clamp term. connections (I.O’s)
  • Communication protocol: RS-422
  • Mounting mode: DIN rail
  • Digital inputs: 32 x digital inputs (24Vdc; Sink/Source)
  • Digital outputs: 32 x digital outputs (Rly NO contacts; 2A / 240Vac or 30Vdc; 10ms response)
  • Ambient air temperature for operation: 0…+55 °C
  • Ambient air temperature for storage: -25…+75 °C
  • Programming languages: Ladder diagram (LD) / Relay symbol language, Structured Ladder / Function Block Diagram (FBD), Structured Text (ST), Sequential Function Chart (SFC)
  • Processing time: 0.065μs / instruction (contact instruction) – 0.000065 ms, 0.642μs / instruction (MOV instruction) – 0.000642 ms
  • Current consumption: 600mA / 0.6A
  • Power consumption: 45 W
  • Equivalent to: FX3U64MRES
  • Compliant with standard(s): CE EMC, CE LVD (Low Voltage Directive, UL / cUL, KC, ABS approval, DNV approval, LR approval, GL approval, BV approval, RINA approval, NK approval, KR approval

Specifications

Attribute Value
Manufacturer Series FX3U
Number of Inputs 32
Output Type Relay
Input Type Sink/Source
Supply Voltage 100 → 240 V ac
Number of Outputs 32
Program Capacity 64000 Steps
Programming Interface Computer, HMI
Programming Language Used Ladder Logic
Mounting Type DIN Rail
Width 90mm
Output Current 8 A
Length 220mm
Maximum Operating Temperature +50°C
Minimum Operating Temperature 0°C
Depth 86mm
Dimensions 220 x 90 x 86 mm
