| Place of Origin | China/Japan |
| Model Number | PFXET6700WAD |
15 inch Wide HMI, FWXGA, 16M colors, Analog, Ethernet I/F x1, COM I/F x2, USB A I/F x1, USB micro-B I/F x1, 24VDC
| Display size | 15 inch |
| Display type | Colour TFT LCD |
| Display colour | 16 million colours |
| Display resolution | 1366 x 768 pixels FWXGA |
| Touch panel | Single touch analogue resistive |
| Brightness | 16 levels |
| Character font | Greek Latin |
| rated supply voltage | 24 V DC +/- 20 % |
| Inrush current | 30 A |
| Power consumption in W | 18.5 W |
| Port Ethernet | 10/100BASE |
| Cut-out dimensions | 394 x 250 mm panel cut dimension |
| Width | 412 mm |
| Height | 268 mm |
| Depth | 50 mm |
| Net weight | 2.52 kg |
