| Place of Origin | China/Japan |
| Brand Name | Omron |
| Model Number | CP1H-XA40DR-A |
CP1H | Omron,
|
CP1H CPU |
Digital input |
Digital output |
Max. I/O points (incl. expansions) |
Input/output functions |
Output type |
Power supply |
PLC port |
Expandability |
Program capacity |
Data memory capacity |
Logic execution speed |
Order code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Y-type with 20 I/O points |
12 |
8 |
300 |
4 Encoder inputs |
Transistor (sinking) |
20.4 to 26.4 VDC |
USB |
Up to 1
1. CP1H CPU series can be expanded with CP1W expansion units (up to 7 units) and CJ1 Special I/O units (up to 2 units).
|
20K steps |
32K words |
0.1 μs |
CP1H-Y20DT-D |
|
X-type with 40 I/O points |
24 |
16 |
320 |
4 Encoder inputs (100 kHz) |
Relay |
84 to 264 VAC |
CP1H-X40DR-A |
|||||
|
4 Encoder inputs (100 kHz) |
Transistor (sinking) |
20.4 to 26.4 VDC |
CP1H-X40DT-D |
|||||||||
|
Transistor (sourcing) |
CP1H-X40DT1-D |
|||||||||||
|
XA-type with 40 I/O points and analog |
4 Encoder inputs (100 kHz) |
Relay |
84 to 264 VAC |
CP1H-XA40DR-A |
||||||||
|
4 Encoder inputs (100 kHz) |
Transistor (sinking) |
20.4 to 26.4 VDC |
CP1H-XA40DT-D |
|||||||||
|
Transistor (sourcing) |
CP1H-XA40DT1-D |
Note: Some expansion units count for 2 unit numbers (eg. CP1W-AD042, CP1W-DA042, CP1W-TS003 and CP1W-TS102) but only 7 expansion unit numbers can be allocated
in a CP1H PLC's configuration. There are more limitations for expansion units like, max. I/O words and total DC power consumption. See manual for more information.
|
Type |
Remarks |
Order code |
|---|---|---|
|
Memory cassette |
512K words (upload/download program) |
CP1W-ME05M |
|
USB programming cable |
A-type male to B-type male (length: 1.8 m) |
CP1W-CN221 |
|
RS-232C option board |
D-Sub, 9 pins, female (15 m max.) |
CP1W-CIF01 |
|
RS-422A/485 option board |
Terminal block (50 m max.) |
CP1W-CIF11 |
|
RS-422A/485 (isolated) option board |
Terminal block (500 m max.) |
CP1W-CIF12 |
|
Ethernet option board |
100/10Base-TX (Auto-MDIX) |
CP1W-CIF41 |
|
LCD display |
4 rows × 12 characters |
CP1W-DAM01 |
|
Expansion I/O connecting cable |
80 cm cable to connect CP1W expansion units |
CP1W-CN811 |
|
CJ1 expansion unit adapter |
Unit to connect CJ1 Special I/O units |
CP1W-EXT01 |
|
Battery |
For replacement purpose |
CJ1W-BAT01 |
CONTACT US AT ANY TIME
