Fuji Electric HMI
>
|
| Place of Origin | China/Japan |
| Brand Name | FUJI |
| Model Number | TS1070i |
|
Specification |
|
|
Display Size |
7 inches |
|
Resolution |
800 x 480 |
|
Color |
TFT color LCD 65,536 colors |
|
Memory |
10.5 MB / 128 Kb |
|
Com 1 |
RS-422/485, Asynchronous, Data length: 7.8 bits, Parity: even / odd / none, Stop bit: 1,2 bits Baud rate: 4800/9600/19200/38400/57600/76800/115200/187500 * 1 bps |
|
Com 2 |
RS-232C Asynchronous, Data length: 7.8 bits, Parity: even / odd / none, Stop bit: 1,2 bits Baud rate: 4800/9600/19200/38400/57600/76800/115200 bps |
|
Com 3 |
RS-422/485 (two-wire system), Asynchronous, Data length: 7.8 bits, Parity: even / odd / none, Stop bit: 1,2 bits Baud rate: 4800/9600/19200/38400/57600/76800/115200 bps |
|
Ethernet |
100BASE-TX/10BASE-T-type (iSeries only) |
|
USB |
2 ports |
|
Power Supply |
DC 24 V ± 10% |
|
Storage Temperature |
-10 to 60 ° C |
|
Operation Temperature |
0 to 50 ° C |
|
Dimensions |
215.0 × 155.0 × 42.0 mm |
|
Panel Cut-Out Dimension |
189.00 x 134.00 mm |
|
Net Weight |
900 gram |
|
Protection |
IP 65 - IP 20 |
